Press Release


PORTWELL TAKES ITS INTEL® ATOM™ PROCESSOR
E620T/E640T/E660T-BASED
ULTRA COMPACT QSEVEN PORTFOLIO TO NEXT LEVEL
New PQ7-M105IT Module Board with PQ7-C100XL Carrier Board
Supports Industrial Temperature Range of -40ºC to 85ºC

FREMONT, CALIF.—September 14, 2010— American Portwell Technology, Inc., (http://www.portwell.com) a wholly owned subsidiary of Portwell, Inc., a world-leading innovator in the embedded computing market and a member of the Intel® Embedded Alliance, announces great news for OEMs and ODMs whose applications require an ultra compact platform and a wide operating temperature range: both the PQ7-M105IT module board and its companion PQ7-C100XL 3.5˝ ESB developer carrier board now support an industrial temperature range of -40ºC to 85ºC. The new PQ7-M105IT module board is the very latest in the company’s growing portfolio of Qseven modules. At a mere 70mm x 70mm (2.75˝ x 2.75˝), the ultra compact PQ7-M105IT module board supports the Intel® Atom™ processor E620T/E640T/E660T System-on-Chip (SoC) and the Intel® Platform Controller Hub EG20T. It supports various processor speed grades from 600MHz, 1.0GHz to 1.3GHz. The PQ7-M105IT module board features 1GB system memory; dual independent display by LVDS/SDVO; one Industrial-grade Gigabit Ethernet; seven USB ports; expansion of two SATA; one SDVO; high definition audio; LPC; four PCI-E x1; and one CAN Bus interface.

The PQ7-C100XL developer carrier board is based on Portwell’s popular 3.5˝ ESB form factor and features one VGA port and one LVDS port for dual independent display; one Gigabit Ethernet port; seven USB ports; two SATA ports; one SDIO socket; expansion via one Mini PCI-E; plus an onboard 12V DC to DC circuit for DC-in applications.

Portwell’s PQ7-M105IT module board with its companion PQ7-C100XL developer carrier board is the ideal solution for a variety of low power, wide temperature and fanless applications such as outdoor embedded systems, industrial control, COTS military and In-Vehicle infotainment systems.

Efficient, Effective Energy Management Using Qseven Technology

“When designing the PQ7-M105IT and PQ7-C100XL, we applied the successful modular computing concept of our COM Express form factor and came up with an even more compact, efficient and economical combination,” says Jimmy Chang, product marketing manager, American Portwell Technology, Inc. “The ultra low power Intel® Atom™ processor E620T/E640T/E660T and Intel® PCH EG20T are housed on the PQ7-M105IT module board and the 3.5˝ ESB form factor-based PQ7-100XL serves as a development kit carrier board with all of the necessary connectors. In this way,” Chang explains, “we were able to maximize Qseven technology to produce a unit that not only outputs under 5W for fanless applications, but also supports a wide -40ºC to 85ºC industrial temperature range. The PQ7-M105IT conserves scarce energy resources, minimizes carbon impact and keeps its energy budgets under control. Individual empowerment is critical; we want our customers to have the ability to choose smarter energy management. By making energy management more personalized, we believe it will lead to valuable changes in behavior and save staggering amounts of energy.”

“Not only does the 70mm x 70mm unit provide a compact footprint, customers will also benefit from the overall cost savings we achieved from the smaller components used to make the boards,” Chang adds.

Expanding Qseven with Extended Temperature Support

The Qseven module has been enhanced by Portwell in response to market demand for an even smaller form factor to take advantage of the Intel Atom processor’s already compact design.
“Since its initial inception, Portwell’s expanding Intel® Atom™ processor-based Qseven portfolio has now grown to include industrial temperature range support,” Chang confirms. “We deliver an extensive and ever-expanding Intel® Atom™ processor-based product portfolio featuring Qseven, Nano-ITX, ETX, COM Express and Mini-ITX.”

Product details:

http://www.portwell.com/products/detail.php?CUSTCHAR1=PQ7-M105IT
http://www.portwell.com/products/detail.php?CUSTCHAR1=PQ7-C100XL

About American Portwell Technology

About American Portwell Technology American Portwell Technology, Inc., is a world-leading innovator in the Embedded Computing market and an Associate member of the Intel® Embedded Alliance. American Portwell Technology designs, manufactures and markets a complete range of PICMG computer boards, embedded computer boards and systems, and rackmount systems for both OEMs and ODMs. American Portwell is both an ISO 9001:2000 and ISO 13485:2003 certified company. The company is located in Fremont, California. For more information about American Portwell’s extensive turnkey, and private-label branding solutions, call 1-877-APT-8899, email info@portwell.com or visit us at http://www.portwell.com.

Intel and Atom are registered trademarks of Intel Corp in the U.S. and other countries. All products and company names referred to herein may be trademarks or registered trademarks of their respective companies or mark holders.
