Industrial ATX Board

Portwell’s industrial ATX motherboards comply with Intel platform which provide ultimate performance and reliability for various industrial applications. The multiple expansion slots with flexible PCIe configuration with rich I/O connectivity can satisfy with different customer requirement.

RUBY-D810-H110 RUBY-D810-H110 7th and 6th generation Intel® Core™ processor series (formerly Kaby Lake and Skylake) and Intel® H110 chipset based industrial ATX motherboard with DDR4 SDRAM, triple displays, two GbE LAN ports, six COM ports
RUBY-D718VG2AR-KBL RUBY-D718VG2AR-KBL 7th generation Intel® Core™ processor family (formerly Kaby Lake) based industrial ATX motherboard with DDR4 SDRAM, triple displays, two GbE LAN ports, six COM ports
RUBY-D718VG2AR RUBY-D718VG2AR 6th generation Intel® Core™ processor family (formerly Skylake) based industrial ATX motherboard with DDR4 SDRAM, triple displays, two GbE LAN ports, six COM ports
RUBY-D716VG2AR RUBY-D716VG2AR Industrial ATX motherboard based on Intel® Q87 chipset supporting Intel® Core™ i5/ i7 processor with HDMI/DVI-D/VGA display, DDR3 SDRAM, dual Gigabit ethernet, USB 3.0, audio and SATA RAID
RUBY-D715VG2AR RUBY-D715VG2AR Industrial ATX motherboard based on Intel® Core™ i3 and Xeon® processor with HDMI/DVI-D/VGA display, DDR3 SDRAM, dual Gigabit ethernet, USB 3.0, audio and SATA RAID
RUBY-D714VG2AR RUBY-D714VG2AR Industrial ATX motherboard based on Intel® Q77 chipset supporting Intel® Core™ i5/ i7 processor with HDMI/DVI-D/VGA display, DDR3 SDRAM, dual Gigabit ethernet, USB 3.0, audio and SATA RAID
RUBY-D712VG2AR RUBY-D712VG2AR Industrial ATX motherboard based on Intel® Q67 chipset supporting Intel® Core™ i3/ i5/ i7 processor with HDMI/DVI/VGA display, DDR3 SDRAM, dual Gigabit ethernet, audio and SATA RAID
RUBY-D711VG2AR RUBY-D711VG2AR Industrial ATX motherboard based on Intel® C206 chipset supporting Intel® Xeon® Core™ i3/ i5/ i7 processor with HDMI/DVI-D/VGA display, ECC DDR3 SDRAM, dual Gigabit ethernet, audio and SATA RAID
RUBY-M710VG2AR RUBY-M710VG2AR Industrial ATX motherboard based on Mobile Intel® QM57 Express chipset supporting Intel® Core™ i3/ i5/ i7 processor with HDMI/DVI/VGA display, DDR3 SDRAM, dual Gigabit ethernet, audio and SATA RAID


Industrial Micro ATX Board

RUBY-D720VG2AR RUBY-D720VG2AR Embedded Micro ATX Industrial motherboard M/B based on Intel® Q87 PCH supporting Intel® Core™ 4th gen. family by LGA1150 package with DVI-D/VGAHDMI display, DDR3 SDRAM, Gigabit ethernet, audio, USB, SATA RAID and AMT 9.0
For 3rd parties memory module comparability, also check (CMTL Advanced Tested Memory List)
*Specifications are subject to change without notice.
