Embedded Computer-on-Module Product Line

COM Express® defines standardized form factors and pin-outs for Computer-on-Modules. The standard includes the mini form factor (84 x 55mm), the compact form factor (95 x 95mm) and the basic form factor (125 x 95mm). To serve industry requirements, the Digital Display Interfaces (DisplayPort, HDMI) and super-fast USB 3.0 were recently added to the pin-out definitions for COM Express® modules.

Type 10 COM Express Module

PCOM-BA01 PCOM-BA01 Intel® Atom® processor E3900 series based COM Express Type 10 Mini module with LPDDR4-2400 MT/s memory, DDI/LVDS/eDP, USB 3.0, GbE, wide voltage support and extended temperature support for -40°C~85°C
PCOM-BA00 PCOM-BA00 Intel® Atom™ processor E3800 series based Type 10 Mini COM Express module with DDR3L SDRAM, NANDrive, eDP/LVDS/DDI, USB 3.0 and GbE
PCOM-B21A PCOM-B21A Intel® Cedarview based Type 10 Mini-COM Express module with the PICMG COM.0 R2.1 specification
PCOM-CA00 PCOM-CA00 Micro-ATX Form Factor Carrier Board For COM Express Type 10 Module for (BGA) CPU embedded Module


Type 7 COM Express Module

PCOM-B701 PCOM-B701 Intel® Atom® processor series (formerly Denverton) based Type 7 COM Express module featuring DDR4 ECC/non-ECC SDRAM on SODIMM slots, PCIe, 10-Gigabit Ethernet, NC-SI interface, SATA III and USB, and support for industrial temperature range -40°C~85°C
PCOM-B700G PCOM-B700G Intel® Xeon® processor D-1500 series based Type 7 COM Express module with DDR4 ECC/non-ECC SDRAM on three SODIMM slots, PCIe, 10-Gigabit Ethernet, SATA III and USB
PCOM-C700 PCOM-C700 ATX form factor COM Express carrier board for Type 7 COM Express module


Type VI COM Express Module

PCOM-B642VG PCOM-B642VG 7th generation Intel® Core™ processor family (formerly Kaby Lake) based Type VI COM Express module with DDR4 SDRAM, VGA, DisplayPort, eDP, Gigabit Ethernet, PCIe, SATA3 and USB
PCOM-B641VG PCOM-B641VG Intel® Atom™ processor E3900 product family (formerly Apollo Lake) based Type VI Compact COM Express module with up to 32GB DDR3L SDRAM on two 204-pin SODIMM slots, DisplayPort, Gigabit Ethernet, 4x PCIe x1 or 1x PCIe x4, SATA, USB, and eMMC, and support for industrial temperature range -40°C~85°C
PCOM-B639VG PCOM-B639VG 6th/7th generation Intel® Core™ processor family (formerly Skylake/Kaby Lake) based Type VI COM Express module (COM.0 rev 2.0) with DDR4 SDRAM, VGA, LVDS, Gigabit Ethernet, SATA3 and USB
PCOM-B638VG PCOM-B638VG 6th/7th generation Intel® Core™ processor family (formerly Skylake/Kaby Lake) based Type VI Compact COM Express module (COM.0 rev 2.0) with DDR4 SDRAM on SODIMM slot, VGA, LVDS, DisplayPort, Gigabit Ethernet, PCIe, SATA, USB and OTG
PCOM-B637VG PCOM-B637VG 6th generation Intel® Core™ processor family (formerly Skylake) based Type VI COM Express module (COM.0 rev 2.0) with DDR4 SDRAM on SODIMM slots, VGA, DisplayPort, Gigabit Ethernet, PCIe, SATA and USB
PCOM-B636VG PCOM-B636VG Intel® Pentium/Celeron Dual/Quad Core N3000 series processor based on Type VI Compact-COM Express2.0 module with DDR3L SDRAM on SO-DIMM slots, VGA, LVDS, Display-port, Gigabit Ethernet, PCIE, SATA and USB
PCOM-B635VG PCOM-B635VG 5th generation Intel® Core™ processor based Type VI COM Express module (COM.0 rev 2.0) with DDR3L SDRAM, VGA, DisplayPort, eDP, Gigabit Ethernet, PCIe, SATA and USB
PCOM-B634VG PCOM-B634VG Intel® Xeon® Processor D Product Family (codename Broadwell DE) based Type VI COM Express module (COM.0 rev 2.0) with DDR4 ECC/non-ECC SDRAM on three SODIMM slots, VGA, HDMI, PCIe x16, 10 GbE, SATA and USB
PCOM-B633VG PCOM-B633VG Intel® 5th Generation Broadwell Core™ i7, i5 and i3 Processors ULT based Type VI COM Express module with DDR3L SDRAM, Gigabit Ethernet, SATA and USB
PCOM-B632VG PCOM-B632VG Intel® Atom E3800 family processor based Type VI COM Express module with DDR3L SDRAM, Gigabit Ethernet, SATA and USB
PCOM-B631VG PCOM-B631VG Intel® Core Haswell ULT processor based Type VI COM Express module with DDR3L SDRAM, Gigabit Ethernet, SATA and USB
PCOM-B630VG PCOM-B630VG Intel®Haswell based Core i7/i5 CPU based Type VI COM Express module with ECC DDR3 SDRAM, Gigabit Ethernet, SATA and USB
PCOM-B219VG PCOM-B219VG Intel® Ivy Bridge based Core i7/i5/i3 CPU based Type VI COM Express module with ECC DDR3 SDRAM, LVDS/Display Port, Gigabit Ethernet, SATA and USB
PCOM-B218VG PCOM-B218VG Intel® Mobile Atom D2550/ N2800/ N2600 Cedar Trail and NM10 based Type VI COM Express module with DDR3 SDRAM, LVDS/Display Port, 10/100 Ethernet, SATA and USB
PCOM-B217VG-VI-ECC PCOM-B217VG-VI-ECC Intel® Mobile Sandy Bridge and QM67 based Type VI COM Express module support ECC DDR3 SDRAM, VGA/LVDS, Gigabit Ethernet, SATA, IDE and USB
PCOM-B216VG-VI-ECC PCOM-B216VG-VI-ECC Intel® Arrandale and QM57 platform with turbo boost technology based Type VI COM Express module with ECC DDR3 SDRAM, HDMI, DisplayPort, Gigabit Ethernet, eSATA and USB
PCOM-C640 PCOM-C640 Nano-ITX Form Factor COM Express Carrier Board for Type VI COM Express Module
PCOM-C609 PCOM-C609 microATX Form Factor COM Express Carrier Board For Type VI COM Express Module
PCOM-C605 PCOM-C605 Mini-ITX Form Factor Carrier Board For COM Express Type VI Module CPU embedded Module
PCOM-C600 PCOM-C600 Micro-ATX Form Factor Carrier Board For COM Express Type VI Module for (BGA) CPU embedded Module


Type II COM Express Module

PCOM-B217VG PCOM-B217VG Intel® Mobile Sandy Bridge and QM67 based Type II COM Express module with DDR3 SDRAM, VGA/LVDS, Gigabit Ethernet, SATA, IDE and USB
PCOM-B216VG-ECC PCOM-B216VG-ECC Intel® Arrandale processor based Type II COM Express module with ECC DDR3 SDRAM and Gigabit Ethernet
PCOM-B216VG PCOM-B216VG Intel® Arrandale processor based Type II COM Express module with DDR3 SDRAM and Gigabit Ethernet
PCOM-B215VG PCOM-B215VG Intel® ATOM™ based Type II micro-COM Express module with DDR2 SDRAM, VGA, Gigabit Ethernet, SATA, USB and NAND Flash
PCOM-C210 PCOM-C210 ATX Form Factor Evaluation Carrier Board For COM Express Type II Module

ETX Module
PEM-E205VLA PEM-E205VLA Embedded ETX module based on Vortex86DX3 processor with up to 2GB DDR3 memory, PCIE, CRT, 24-bit LVDS, ISA, I2C, SPI, Fast Ethernet, UART FIFO, USB, IDE and SATA
PEM-E200VLA PEM-E200VLA Intel® ATOM™ N270 CPU embedded ETX module with DDR2 SDRAM, VGA, Fast Ethernet, SATA and USB
PEM-C200 PEM-C200 Micro-ATX Form Factor Evaluation Carrier Board for ETX Module
For 3rd parties memory module comparability, also check (CMTL Advanced Tested Memory List)
*Specifications are subject to change without notice.
