Intel® Core™ i3/i5/i7 Processor based Mini-ITX Board

The Mini-ITX form factor, defined by the chipset manufacturers in Taiwan, is a highly integrated all-in-one x86-based embedded computer board that measures a mere 170mm x 170mm. Its compact size and all-in-one design simplifies and accelerates the implementation of an embedded PC system. Portwell’s Mini-ITX computer boards and barebones systems offer a wide selection of microprocessors, power efficient technologies, peripheral I/Os, expansions and mechanical form factors. Whether you’re working on medical instruments, thin network devices or digital media systems, Portwell’s Mini-ITX boards and barebone systems are the perfect solutions to help you to deliver your products on time and stay one step ahead of the competition. With 20 years of experience in the design and manufacture of single board computers, Portwell provides not only one-stop shopping for off-the shelf products, but also custom-built solutions tailor-made to suit your needs.

WADE-8210-H110 WADE-8210-H110 7th and 6th generation Intel® Core™ processor series (formerly Kaby Lake and Skylake) and Intel® H110 chipset based Mini-ITX board with DDR4 SDRAM, triple displays, two GbE LAN ports, six COM Ports
WADE-8017-KBL WADE-8017-KBL 7th generation Intel® Core™ processor family (formerly Kaby Lake) based Mini-ITX board with DDR4 SDRAM, triple displays, two GbE LAN ports, six COM Ports
WADE-8017 WADE-8017 6th generation Intel® Core™ processor family (formerly Skylake) based Mini-ITX board with DDR4 SDRAM, triple displays, two GbE LAN ports, six COM Ports
WADE-8016 WADE-8016 Intel® Mini-ITX board with H81 PCH chipset supporting Intel® 4th Gen. i3/i7 processor in LGA 1150 package based Mini-ITX with VGA/DVI/HDMI, Two GbE LAN, SATA III, USB 3.0
WADE-8015 WADE-8015 Intel® Mini-ITX board with Q87 PCH chipset supporting Intel® Next Gen. Dual Core / Quad Core processor in LGA 1150 package based Mini-ITX with VGA/DP/HDMI, Two GbE LAN, SATA
WADE-8013 WADE-8013 Intel® Mini-ITX board with Q77 PCH chipset supporting Intel® Next Gen. Dual Core / Quad Core processor in LGA 1155 package based Mini-ITX with VGA/DVI/HDMI, Two GbE LAN, SATA and AMT 8.0
WADE-8012 WADE-8012 Intel® Mini-ITX board with Q67 PCH chipset supporting Intel® Core™ i3/ i5/ i7 LGA-1155 processor based Mini-ITX with VGA/DVI/HDMI, Two GbE LAN, SATA RAID and AMT 7.0
WADE-8011 WADE-8011 Intel® Mini-ITX board with Intel C206 chipset supporting Intel®Xeon™ E3-1225 LGA-1155 processor based Mini-ITX with VGA/DVI/HDMI, Two GbE LAN, SATA RAID and AMT 7.0
WADE-8022 WADE-8022 Intel® Mini-ITX board with QM87 PCH chipset supporting Intel® mobile 4th Gen. Celeron, i3/i5/i7 processor(BGA) based Mini-ITX with LVDS (24bits)/DVI-I/DP/HDMI, Two GbE LAN, SATA
WADE-8020 WADE-8020 Intel® Mini-ITX board with QM57 Chipset supporting Intel®Core™ i3 / i5 / i7 mobile processor based Mini-ITX with VGA/DVI/HDMI/LVDS display, Two GbE LAN, SATA RAID and iAMT 6.0
For 3rd parties memory module comparability, also check (CMTL Advanced Tested Memory List)
*Specifications are subject to change without notice.
