| Specification | |
|---|---|
| Processor | NVIDIA® Jetson Orin™ NX 8GB 6-core Arm® Cortex®-A78AE v8.2 64-bit CPU 1.5MB L2 + 4MB L3 NVIDIA® Jetson Orin™ NX 16GB 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3 |
| Memory | Support up to 16GB LPDDR5 on board |
| Storage | 1 x M.2 Key-M NVMe PCIe x4 2280 |
| Ethernet | 2 x 1 GbE LAN |
| Serial Port | 2 x COM Ports Support RS-232/422/485 1 x CANbus FD |
| USB | 3 x USB 3.2 Gen2 x1 (10Gbps) Type A 1 x USB 3.2 Gen2 x1 (10Gbps) Type C |
| GPIO | 1 x 8-bit Digital I/Os |
| Display | 1 x HDMI® 2.0b |
| Other | Power Button, Reset Button, Recovery Button |
| LED | Power, Storage |
| Antenna | 6 x SMA Antenna holes for LTE / 5G / Wi-Fi |
| SIM Slots | 2 x Nano-SIM |
| M.2 | 1 x B Key w/ 3042/3052 1 x E Key w/ 2230 |
| Dimension(WxDxH) | 152 x 109 x 63 mm (5.98" x 4.29" x 2.48" ) |
| Weight | 1.31 kg |
| Power Supply | Terminal Block 12~24V |
| Mounting | Wall Mount, DIN Rail Mount |
| Vibration | 1G 5~500Hz with Wall mount (IEC/EN 60068-2-6) 0.5G 5~500Hz with Din rail (IEC/EN 60068-2-6) |
| Shock | 50G 11m sec with Wall mount (IEC/EN 60068-2-27) 15G 11m sec with Din rail (IEC/EN 60068-2-27) |
| Operating Temperature | -20 ~ 60 °C (-40.0 ~ 140.0 °F) |
| Storage Temperature | -40 ~ 85 °C (-40.0 ~ 185.0 °F) |
| Cooling | Fanless |
| BSP | NVIDIA JetPack SDK 6.2 |
| Relative Humidity | 5% to 95%, non-condensing |
| Certification | CE/FCC/UKCA Class A |
| OS | Linuxâ„¢ |
| Ordering Guide | |
|---|---|
| PJAI-1100-OX8G | (R).ATO.PJAI-1100-OX8G.Embedded System. Nvidia Jetson Orin NX(8GB) (260pin SO-DIMM),12-24V |
| PJAI-1100-OX16G | (R).ATO.PJAI-1100-OX16G.Embedded System. Nvidia Jetson Orin NX(16GB) (260pin SO-DIMM),12-24V |
