AREMO-3194


  • Hover to zoom

Features

  • IEEE 1394 port and two USB ports on the front panel
  • Dedicate cooling fans for expiring the heat on the hot spots within the chassis
  • Dustproof front-access air filter for easy cleaning and replacing
  • Lockable front door provides greater security
  • Thumb lock for greater security and to operate system more easily
19"3U rack-mount chassis for ATX M/B platform(adopt 2U power supply)

Specification
ConstructionHeavy-duty steel
Drive_Bay_externalSlim type CD-ROM x1, Hot-swap 3.5" HDD x2
Air FilterOne internal replaceable air filter
Cooling_FanTwo 8 cm ball-bearing fans
IndicatorHDD x1+ Power on/off x1
SwitchPower on/off x1 (with a protection cap) x1, System reset x1
SpeakerOne speaker
ConnectorTwo USB ports equipped on the front panel
Standard_ColorSilver, Beige, Black
Dimension482 x 441.6 x 88.4 mm
WeightNet 11.0 kg; Gross 12.0 kg
BackplanePBP-06V4 Vertical 6-slot (4xPCI) PICMG backplane PBP-06V Vertical 6-slot ISA backplane
Input Voltage90V ~ 264V AC, full range
Input Frequency47 ~ 63Hz
Input Current6A@90V
Efficiency> 68%
MTBF75,145 hrs
EMI_Safety_ApprovalUL, TUV, CE, FCC, CB, CSA, SEMKO, FIMKO, NEMCO, DIMCO
Temperature_HumidityOperating 0°C ~ 50°C, 20 ~ 85%RH Storage -40°C ~ 70°C, 10 ~ 90%RH
Operating Temperature0°C ~ 50°C
Storage Temperature-40°C to +70°C
Relative_Humidity5% ~ 95°%, non-condensing
Vibration"5~7 Hz 0.5"" double amplitude displacement 7~2000 Hz 1.5g acceleration"


Ordering Guide

    AREMO-3194-MX19" 3U rack-mount chassis with for ATX M/B fit ATX, 2U PSU
    AREMO-3194-MX/B19" 3U black rack-mount chassis for ATX M/B fit ATX, 2U PSU
    AREMO-3194E-MX19" 3U rack-mount chassis for ATX M/B fit ATX, PS/2 PSU
    AREMO-3194E-MX/B19" 3U black rack-mount chassis for ATX M/B fit ATX, PS/2 PSU
