AREMO-4196

19" 4U industrial rack-mount chassis with 14 slots



Features

  • Three 5.25" and two internal 3.5" HDD drive bays for RAID 0, 1, 5 & CD-ROM
  • Four USB ports on the front panel
  • Dual 12cm ball-bearing cooling fans for better ventilation
  • Two card retainer positions
  • PS/2 or redundant power supply installable
  • ATX M/B applicable, especially for big-ATX size M/B
  • Easily detached and washable air filter
  • Equipped with fan control card to detect fan fail



19" 4U industrial rack-mount chassis with 14 slots

Specification
ConstructionHeavy-duty steel with aluminum front panel
Drive_Bay_internal"3x 5.25"", 1x 3.5""HDD 2x 3.5"""
Card_RetainerThree locations for one card retainer
Air FilterTwo replaceable air filter
Cooling_FanTwo 12cm ball-bearing cooling fans
Indicator1x Power On/Off, 1x HDD
Switch1x Power On/Off, 1x System reset
SpeakerOne speaker
ConnectorT2x USB ports on the front panel
Standard_ColorSilver, Black
Dimension482 x 481 x 177 mm
WeightNet 13.5 kg; Gross 14.5 kg
Backplane"PBPE-13A8 14-slot [PCIe (4), PCI (8), PCI-X (0)] active PICMG1.3 backplane PBPE-13A4 14-slot [PCIe (8), PCI (4), PCI-X (0)] active PICMG1.3 backplane PBPE-12A9 14-slot [PCIe (2), PCI (9), PCI-X (0)] active PICMG1.3 backplane PBPE-12P4 14-slot [PCIe (8), PCI (4), PCI-X (0)] PICMG 1.3 backplane PBPE-11A3 14-slot [PCIe (8), PCI (3), PCI-X (0)] active PICMG1.3 backplane"
Maximum_output350W active PFC
Output_Voltage_Current+5V@12A; +12V1@18A; +12V2@18A; +3.3V@18A; -12V@0.3A,+5Vsb@2.5A
Input Voltage90V ~ 264V AC, full range
Input Frequency50 ~ 60Hz
Input Current8A@115V, 8A@230V
Efficiency> 80%
MTBF100,000 hrs
EMI_Safety_ApprovalUL, TUV, CE, FCC, CB, VCCI, 80PLUS
Temperature_Humidity"Operating 5°C ~ 50°C, 20% ~ 85%RH Storage -40°C ~ 70°C, 10% ~ 95%RH"
Operating Temperature0°C ~ 55°C
Storage Temperature-20°C to 80°C
Relative_Humidity5% ~ 95°%, non-condensing
Vibration"5~7 Hz 0.5"" double amplitude displacement 7~2000 Hz 1.5g acceleration"


Ordering Guide
AREMO-419619" 4U Rack-mount chassis for PICMG version
AREMO-4196-MX19" 4U Rack-mount chassis for M/B version
AREMO-4196-MX-4201P19" 4U rack-mount chassis for ATX motherboard with active 420W ATX, PFC power supply
AREMO-4196-00-4201P19" 4U rack-mount chassis for PICMG version and 420w ATX, PFC power supply
