*Status: Preliminary
About Femto-ITX
Femto‑ITX is a compact 84 x 55 mm embedded motherboard form factor optimized for highly integrated, low‑power system designs. By consolidating compute, memory, and essential I/O onto a single board, it reduces system complexity while improving thermal efficiency and long‑term reliability. Its minimal footprint makes it well suited for space‑constrained edge applications such as industrial control, medical devices, and intelligent IoT endpoints.
| Specification | |
|---|---|
| Form Factor | Femto-ITX (84 x 55 mm) |
| Processor | Intel® Core™ 3 Processor 304 Intel® Core™ 5 Processor 315 Intel® Core™ 7 Processor 350 |
| Processor Graphics | Intel® Graphics, up to 2 Xe cores (depending on SKU) |
| Memory | Onboard LPDDR5 memory up to 16GB |
| Storage | Onboard UFS 3.1 up to 256GB |
| Ethernet | 1 x 2.5GbE (Intel® I226LM), supporting 10/100/1000/2500 Mbps (rear I/O) |
| USB | 2 x USB 3.2 Gen2 Type-A (read I/O) 2 x USB 2.0 (pin header) |
| M.2 | 1 x M.2 Key E 2230 |
| Security | TPM 2.0 |
| Display | 1 x HDMI® 1.4, up to 3840 x 2160 @ 30Hz (rear I/O) 1 x eDP, up to 3840 x 2160 @ 60Hz |
| GPIO | 8-bit digital I/O |
| Other Expansion I/O | 1 x I2C/SMBus |
| Dimension | 84 x 55 mm (3.31" x 2.17") |
| Power Supply | 2-pin terminal block or DC jack |
| Storage Temperature | -40°C to 85°C (-40°F to 185°F) |
| Operating Temperature | 0°C to 60°C (32°F to 140°F) |
| Relative Humidity | 5% to 95%, non-condensing |
| Certification | CE, FCC, UKCA |
| OS | Windows 11 IoT Enterprise LTSC 2024, Ubuntu 24.04 LTS |
| Portwell Special Feature | Portwell Engineering Toolkits (PET) |
| Ordering Guide | |
|---|---|
| FEMTO-8010 | Femto-ITX Industrial Motherboard based on Intel® Core™ Processors (Series 3) with Dual Display, 2.5GbE LAN, Dual USB 3.2 Gen2, M.2, LPDDR5, UFS 3.1 |
