| Specification | |
|---|---|
| Form Factor | Portwell NIC Module |
| LAN Controller | Intel i350-AM4 |
| Ethernet Port | 4x RJ-45 GbE Ports |
| Bypass | 2 segments |
| Bus Type | 8x Proprietary PCIe Gen2 |
| Dimension (WxDxH) | 85mm x 152mm x 16mm (3.35' x 5.98' x 0.63') |
| Operating Environment | Temperature: 0 - 45°C (32 - 113°F) Humidity: 20 - 90% RH |
| Storage Environment | Temperature: 0 - 70°C (14 - 158°F) Humidity: 5 - 95% RH @ 55°C |
| OS Support | Linux / Windows / FreeBSD |
| Ordering Guide | |
|---|---|
| NIP-51243 | Intel® i350-AM4 LAN Controller based 4 Ports GbE RJ-45 Bypass Network Adapter |
