PNSR-5000S

1U Server based on Intel® Xeon® D-1800/D-1700 Series SoC Featuring Onboard 2x 2.5GbE RJ45, 2x 25GbE SFP28, 1x OCP NIC 3.0 slot



Features

  • Intel® Xeon® D-1800/D-1700 Series SoC
  • Up to 4x DDR4 2933MHz ECC RDIMMs
  • 2x 2.5GbE RJ45 Copper ports (Optional 6x 2.5GbERJ45)
  • 2x 25GbE SFP28 Fiber ports up to 50Gbps throughput
  • 1x PCIe Gen4 x16 or 2x PCIe Gen4 x8 slots, optionalOCP NIC 3.0 slot
  • 2x 2.5” HDD/SSD trays, 1x M.2 Key M for storage
  • 1x M.2 Key B for 4G/5G/LTE module, 1x M.2 Key E forWiFi module
  • Onboard TPM 2.0 for security



In the rapidly evolving world of data centers and network management, efficiency, scalability, and robust performance are more critical than ever. The Portwell PNSR-5000S 1U server, featuring the Intel® Xeon® D-1800 processor series, ample storage, and a total of 2x 25G and up to 6x 2.5G Ethernet ports, is designed to fit seamlessly into your rack while delivering exceptional computing capabilities.

The PNSR-5000S is ideal for various use cases, including network services managing DNS, DHCP, and other critical services, virtualization running multiple virtual machines without compromising performance, web hosting, and more.

Additionally, the Portwell PNSR-5000S, based on the Intel Xeon D-1800 processors, has significant potential in 5G Telco/Edge IT infrastructure and AI applications, such as 5G Telco Infrastructure, Edge IT Infrastructure, and AI and Machine Learning.

In 5G Telco Infrastructure, the PNSR-5000S server is well-suited for 5G applications due to its high-speed and low-latency networking capabilities. It can serve as Customer Premise Equipment (CPE) or be deployed in Multi-access Edge Computing (MEC), which is crucial for low-latency applications in 5G networks.

In Edge IT Infrastructure, the space-saving 1U form factor and robust computing power make the PNSR-5000S ideal for edge computing scenarios. It can process data at the source, reducing latency and bandwidth usage, which is essential for real-time analytics and IoT applications.

In AI and Machine Learning, the PNSR-5000S server, with up to 10 cores featuring Intel® Hyper-Threading Technology, Intel® Deep Learning Boost, and support for AI acceleration modules, can handle AI workloads, including machine learning model training and inference. Its high-speed I/Os and memory capacity are beneficial for processing large datasets and running complex algorithms.


Specification
Form Factor1U 19" Rackmount
CPUIntel® Xeon® D-1800/D-1700 Series SoC Up to 10 cores, 90W TDP
BIOSAMI Aptio® V UEFI BIOS
IPMIN/A
System MemoryTotal 4 DIMMs (2DPC)
(1DPC) 2x DDR4 2933MHz ECC LRDIMM, up to 128GB
(2DPC) 4x DDR4 2933MHz ECC RDIMM, up to 256GB
ExpansionOCP NIC 3.0 slot (extended depth) or PCIe slots:
Optional 1x OCP NIC 3.0 (PCIe Gen4 x16)
Optional 1x PCIe Gen4 x16 (or 2 x8 via riser card), FH HL

M.2:
1x M.2 Key B 3052 socket with dual SIM card slots (USB, SATA)
1x M.2 Key E 2230 socket (USB)
Ethernet Ports2x 10/25GbE SFP+/SFP28, Max 50Gbps throughput
2x 2.5GbE RJ45 (Optional 6x 2.5GbE RJ45) via Intel® Ethernet Controller I226
Storage2x 2.5” SATA 3.0 HDD/SSD pluggable trays (front)
1x M.2 Key M 2280 socket (NVMe or SATA)
Power Supply500W Redundant AC Power Supply AC 100V-240V @47Hz-63Hz
CoolingCPU: Passive heatsink System: 3x fans
SecurityOnboard TPM 2.0
OS SupportLinux
Dimension481.94mm (W) x 362.7mm (D) x 44.34mm (H)
18.97" (W) x 14.28" (D) x 1.75" (H)
Serial Port1x RJ45 Console port
USB2x USB 3.2 Gen 1 ports, Type A 2x USB 2.0 headers onboard
LCD Panel(optional) 2x16 characters, 4x keypads
Display1x HDMI connector at rear I/O
LEDPower/HDD LEDs
4x SFP28 port LEDs (Link + Speed)
PowerFront:
1x Power button
1x Reset button

Rear:
2x AC/DC power inlets (by SKU)
Operating Environment0°C to 40°C (32°F to 104°F)
Storage Environment-20°C to 70°C (-4°F to 158°F)
Humidity5% to 95% RH, non-condensing
CertificationCE/FCC Compliance


Ordering Guide
In Process1U Server based on Intel® Xeon® D-1800/D-1700 Series SoC Featuring Onboard 2x 2.5GbE RJ45, 2x 25GbE SFP28, 1x OCP NIC 3.0 slot
