AREMO-2173MX

19" 2U Chassis for Micro-ATX and Mini-ITX Board



Features

  • One slim CD-ROM and two hot-swap 3.5" HDD (SATA) Drive bays
  • Two USB ports on the front panel
  • Two 7cm ball-bearing cooling fans for better ventilation
  • One power On/Off switch with protection cap and one touch free reset for secure access



19" 2U industrial rack-mount chassis for Micro-ATX or mini-ITX mother board

Specification
ConstructionHeavy-duty steel
Drive_Bay_external1x Slim type CD-ROM 2x Hot-swap 3.5" HDD
Air FilterOne external replaceable air filter
Cooling_FanTwo 7cm ball-bearing fans
Indicator1x HDD+ 1x Power On/Off
Switch1x Power On/Off (with a protection cap), 1x System reset
SpeakerOne speaker
Connector2x USB ports equipped on the front panel
Standard_ColorSilver, Black
Dimension482 x 429.2 x 88.6 mm
WeightNet 11.0 kg; Gross 12.0 kg
Maximum_output350W active PFC
Output_Voltage_Current+5V@12A; +12V1@18A; +12V2@18A; +3.3V@18A; -12V@0.3A,+5Vsb@2.5A
Input Voltage90V ~ 264V AC, full range
Input Frequency50 ~ 60Hz
Input Current8A@115V, 8A@230V
Efficiency> 80%
MTBF100,000 hrs
EMI_Safety_ApprovalUL, TUV, CE, FCC, CB, VCCI, 80PLUS
Temperature_Humidity"Operating 5°C ~ 50°C, 20% ~ 85%RH Storage -40°C ~ 70°C, 10% ~ 95%RH"
Operating Temperature0°C ~ 55°C
Storage Temperature-20°C to 80°C
Relative_Humidity5% ~ 95°%, non-condensing
Vibration"5~7 Hz 0.5"" double amplitude displacement 7~2000 Hz 1.5g acceleration"


Ordering Guide
AREMO-2173MX-D3501P19" 2U rack-mount chassis for micro-ATX or mini- ITX M/B with 350W ATX, active PFC power supply
AREMO-2173MX19" 2U rack-mount chassis for micro-ATX or mini- ITX M/B
AREMO-2173MX-3502P19" 2U rack-mount chassis for micro-ATX or mini- ITX M/B and 350W active PFC redundant power supply
