AREMO-2199-MX

19" 2U industrial rack-mount chassis for ATX/Micro-ATX/Mini-ITX motherboard



Features

  • 9x 3.5” HDD Drive bays (or 3x 2.5” HDD/SSD)
  • Four 8cm ball-bearing cooling fans for better ventilation
  • Two USB 2.0 ports on the front panel
  • All I/O ports, Buttons, LEDs, Drive bays, AC inlet located on the front side



AREMO-2199-MX is a 2U rack-mount chassis designed for ATX, Micro-ATX, or Mini-ITX motherboards. It features two USB interfaces on the front panel, nine 3.5" HDD drive bays, and seven half-size PCI/PCIe expansion slots. Additionally, it can be equipped with a highwattage 2U form factor PSU. AREMO-2199-MX is suitable for Factory and Server applications.

Specification
ConstructionHeavy-duty steel with aluminum front panel
Drive Bay9x 3.5" HDD (or 3x 2.5" HDD/SSD)
Cooling Fan4x 8cm ball-bearing cooling fans
Indicator1x Power On/Off LED, 1x HDD LED
Switch1x Power On/Off, 1x System reset
Connector2x USB ports on the front panel
Expansion slots7x half-size PCI/PCIe expansion slots, vertical insert
Standard ColorBlack
Dimension650 x 428 x 88.5 mm
Weight8.5 Kg
Input Voltage90V ~ 264V AC, full range
Input Frequency50 ~ 60Hz
Input Current10A@110V, 5A@240V
Efficiency> 80%
MTBF100,000 hrs
EMI & Safety ApprovalCE, FCC
Operating Temperature0°C ~ 50°C
Storage Temperature0°C ~ 70°C
Relative Humidity5% ~ 95°%, non-condensing
Vibration5~7 Hz: 0.5” double amplitude displacement 7~2000 Hz: 1.5g acceleration


Ordering Guide
AC1-3259(R).AREMO-2199-MX. 19” 2U rack-mount chassis for M/B
