AREMO-8164


  • Hover to zoom

Features

  • Two 5.25" drive bays for CD-ROM or mobile rack, easy to install software and mirror disk (RAID1)
  • Two USB ports on the front panel
  • Can be vertically or horizontally mounted, easy to fit into space limited environment
  • One 12 cm ball-bearing cooling fan for better ventilation
  • One replaceable air filter for easily cleaning
  • Two adjustable positions for hold-down card retainers provide better protection from vibration
  • Both 8-slot ISA and PICMG backplane applicable; easy to change different backplanes
  • Field replaceable power supply bracket for both normal PS/2 and PS/2 redundant power supply, easy for changing defective power supply
8-slot full-sized industrial node chassis (Shoe-box)

Specification
ConstructionHeavy-duty steel
Drive_Bay_internal2x 3.5" HDD
Drive_Bay_external1x 5.25"
Card_RetainerTwo locations for one card retainer
Air FilterOne replaceable air filter at the front door
Cooling_FanOne 12cm ball-bearing fan
Indicator1x Power On/Off, 1x HDD
Switch1x Power On/Off, 1x System reset
SpeakerOne speaker
Connector2x USB ports on the front panel
Standard_ColorSilver, Black
Dimension219 x 448 x 160 mm
WeightNet 6.5 kg; Gross 8.0 kg
Backplane"PBP-06P4 6-slot [PCIe (1), PCI (4), PCI (0)] PICMG 1.0 backplane PBP-06P3 6-slot [PCIe (2), PCI (3), PCI (0)] PICMG 1.0 backplane PBP-06P2 6-slot [PCIe (3), PCI (2), PCI (0)] PICMG 1.0 backplane"
Maximum_output350W active PFC
Output_Voltage_Current+5V@18A; +12V1@16A; +12V2@16A; +3.3V@16A; -12V@0.3A, -5V@0.3A,+5Vsb@2.5A
Input Voltage90V ~ 264V AC, full range
Input Frequency47 ~ 63Hz
Input Current6A@115V, 3A@230V
Efficiency> 80%
MTBF100,000 hrs
EMI_Safety_ApprovalUL, TUV, CE, FCC, CB
Temperature_Humidity"Operating 0°C ~ 50°C, 5% ~ 90%RH Storage -20°C ~ 80°C, 5% ~ 95%RH"
Operating Temperature0°C ~ 55°C
Storage Temperature-20°C to 80°C
Relative_Humidity5% ~ 95°%, non-condensing
Vibration"5~7 Hz 0.5"" double amplitude displacement 7~2000 Hz 1.5g acceleration"


Ordering Guide

    AREMO-8164-08P4-330X8-slot full-sized industrial node chassis with 8-slot (4xPCI) PICMG backplane and 330W ATX power supply
    AREMO-8164-08P4-D3501P8-slot full-sized industrial node chassis with 8-slot (4xPCI) PICMG backplane and 350W Active PFC ATX power supply
