MEDS-A200

Medical Edge AI System powered by Intel® Core™ Series 2 and 14th/13th/12th Gen Intel® Core™ processors with option to build with NVIDIA RTX PRO™ 2000 Blackwell GPU

×

1

2

3

4

❮ ❯

Features

Supports Intel® Core™ Series 2 processors (codename Bartlett Lake) for high-performance computing
Dual SO-DIMM slots supporting DDR5 memory up to 96GB
PCIe Gen5 x16 expansion slot, optimized for low-profile NVIDIA RTX PRO™ 2000 Blackwell GPUs
Optional internal antenna support to maintain a sleek system profile

Documents & Downloads

Engineered for next-generation clinical diagnostics, the MEDS-A200 edge AI system leverages Intel® Core™ Series 2 (codename Bartlett Lake) and 14th/13th/12th Gen Intel® Core™ processors to enable real-time data processing at the point of care. With support for NVIDIA RTX PRO™ 2000 Blackwell GPU and PCIe Gen5 x16, it delivers high-bandwidth throughput essential for AI-enhanced medical imaging, surgical robotics, and complex pathology analysis.

Specification
Processor	Intel® Core™ Series 2 and 14th/13th/12th Gen Intel® Core™ Processors in LGA1700 package
Chipset	Intel® Q670E
BIOS	AMI uEFI BIOS
Memory	- Supports dual-channel DDR5 SO-DIMM memory, up to 96GB - Supports DDR5 5600 MT/s (1DPC, 1R) and DDR5 5200 MT/s (1DPC, 2R) SO-DIMM memory on all Intel® Core™ i9, i7, and select i5 SKUs
Storage Devices	- Supports 4x SATA III ports - Supports RAID 0, 1, 5, 10
Graphics Controller	Intel® UHD Graphics 770/730/710; support DirectX 12, OpenGL 4.6/4.5, OpenCL 3.0, Vulkan 1.4 *Depending on CPU SKU
Watchdog Timer	Programmable watchdog timer
Hardware Monitoring	System monitor(Voltage, Fan Speed and Temperature)
Expansion Interface	- 1x PCIe x16 Gen 5 - 1x M.2 Key E 2230 with PCIe x1 and CNVI for Wireless - 1x M.2 Key M 2242/2260/2280 with PCIe x4 and SATA3
Audio	Audio Jack with Line-out / Line-in with Realtek ALC897
Ethernet	- Intel® I210AT (1GbE) and Intel® I225LM (2.5GbE) - 2x RJ45 connectors on rear I/O
Serial Port	- 1x RS232/422/485 port
USB	- 3x USB3.2 (Gen2) (2x Type A + 1x Type C) - 1x USB3.2 (Gen1) - 4x USB2.0
Display	- 3x DP - 1x HDMI
Form Factor	Mini-ITX
Dimension	264.2mm x 204.3mm x 96.5mm 10.4” x 8.04” x 3.8”
Power Input	300W ATX PSU
Weight	2.4kg (5.3 lbs)
