| Specification | |
|---|---|
| Processor | - Intel® Core™ Series 2 and 14th/13th/12th Gen Intel® Core™ processors in LGA1700 package, 125W TDP - 8x DMI 4.0 - Supports Intel® Turbo Boost, Hyper-Threading, Virtualization, Thermal Monitoring, Trusted Execution and SpeedStep Technology (depends on CPU) |
| Chipset | Intel® R680E/Q670E |
| BIOS | AMI uEFI BIOS |
| Memory | - Supports up to 64GB DDR5 4800 MHz SDRAM on two 262-pin SO-DIMM sockets - Supports both ECC and non-ECC |
| Display Interface | - 1x DP 1.4: up to 7680x4320 @ 60Hz - 1x HDMI 2.1: up to 4096x2160 @ 60Hz |
| Storage Devices | - 1x hot-swappable SATAIII drive - 1x M.2 Key M 2280 NVMe SSD |
| Watchdog Timer | Programmable watchdog timer, time out period from 0.5 secs. to 254.5 secs. |
| Hardware Monitoring | System monitor (Voltage, Fan Speed and Temperature) |
| Expansion Interface | - 2x PCIe Gen 5 x16 slots (1 x16 or 2 x8 signal) - 2x PCIe Gen 4 x4 slots |
| Graphics Controller | Intel® UHD Graphics 770/730/710*; support DirectX 12, OpenGL 4.6/4.5*, OpenCL 3.0, Vulkan 1.4 *Depending on CPU SKU |
| Display Interface | - 1x DP 1.4: up to 7680x4320 @ 60Hz - 1x HDMI 2.1: up to 4096x2160 @ 60Hz |
| USB | - 2x USB 3.2 Gen 2 ports on Rear I/O (10Gb/s) - 2x USB 3.2 Gen 1 ports on Rear I/O (5Gb/s) - 4x USB 3.2 ports in the front |
| Ethernet | - Marvell AQC114C 5G Gigabit Ethernet controller - 2x 5GbE ports |
| Audio | Realtek ALC888S HDA codec, one 7.1 channel onboard audio pin header |
| Dimension (WxHxD) | 19.3 cm x 18.9 cm x 47.5 cm (7.6" x 7.4" x 18.7") |
| Power Input | 1600W hot-swappable CRPS PSU (100-240VAC) |
| Environment | - Operating Temperature: 0°C to 50°C - Storage Temperature: -20°C to 80°C - Relative Humidity: 10~95%, RH |
| Weight | 7.8 kg (17.2 lbs) |
| Ordering Guide | |
|---|---|
| NURO-824E | Edge GPU Workstation with Intel® Core™ Series 2 and 14th/13th/12th Gen Intel® Core™ i9/i7/i5/i3 Processor Featuring PCIe Gen 5 x16 Slot Optimized for an NVIDIA RTX PRO™ 6000 Blackwell Workstation Edition GPU |
