SMARC Modular Embedded System Board

The SMARC ("Smart Mobility ARChitecture") is an extremely versatile, small form factor computer-on-module ideal for those who require an inexpensive, power-efficient option with high performance benchmarks. These SMARC module sizes are available in 82mm x 50mm and 82mm x 80mm with 314 edge fingers that mate with a low profile 314 pin 0.5mm pitch right angle connector.

Though these SMARC modules boast broad levels of integration and power-efficient processing capabilities, they are particular well-suited to industrial automation, transportation, and communication equipment applications, to name a few—though this is hardly a comprehensive list of uses.

Browse our selection of SMARC modules today. If you have any questions or would like to schedule a demo, contact us and we will be happy to accommodate.

SMARC Modular Embedded System Board

PSMC-M640F2 PSMC-M640F2

SMARC 2.0 Module based on NXP® i.MX 6 series of applications processors, support DDR3L DRAM up to 2GB, triple display interfaces, dual Gigabit Ethernet, up to 64GB eMMC, and wide input voltage range (3~5.25 VDC)

PSMC-M1011 PSMC-M1011

SMARC 2.0 Module based on Intel® Atom® processor E3900 series, Intel® Pentium® processor N4200, and Intel® Celeron® processor N3350, support LPDDR4 SDRAM up to 8GB, 24-bit LVDS, DisplayPort/HDMI, Gigabit Ethernet, and extended operating temperature range, -40°C~85°C

PSMC-M101 PSMC-M101

SMARC 2.0 Module based on Intel® Atom™ processor E3900 series, Intel® Pentium® processor N4200, and Intel® Celeron® processor N3350, support LPDDR4 DRAM up to 8GB, 24-bit LVDS, DisplayPort/HDMI, Gigabit Ethernet, and Infineon® OPTIGA™ Trust

PSMRC-M640F PSMRC-M640F

Based on Freescale™ i.MX6 family, ARM® Cortex® A9, Solo / Dual / Quad core processor with onboard 1GB DDR3 (up to 2GB), PCIe 1-lane interface, VGA, HDMI, single LVDS 1-ch or dual LVDS (18/24-bit) 2-ch and CAN Bus. It i s design with series of Qseven form factor.

PSMRC-M310T PSMRC-M310T

Based on embedded TI™ AM3354 Single-core processor, an ARM® Cortex® A8 processor. It is design with SMARC form factor. Best cost-effective entry model to replace original markets of ARM9 and ARM11.

SMARC Carrier Board

PSMRC-C300ARM PSMRC-C300ARM

Mini-ITX Form Factor Carrier Board for SMARC Module with GbE, HDMI, VGA and dual LVDSe

*Specifications are subject to change without notice.
